Hikvision DS-2CE10DF0T-PF 1080p 3,6mm IR 20metre ColorVu Bullet Kamera

2 MP ColorVu Fixed Mini Bullet Camera

    High quality imaging with 2 MP, 1920 × 1080 resolution
    24/7 color imaging with F1.0 aperture
    3D DNR technology delivers clean and sharp images
    2.8 mm, 3.6 mm, 6 mmfixed focal lens
    Up to 20 m white light distance for bright night imaging
    One port for four switchable signals (TVI/AHD/CVI/CVBS)
    Water and dust resistant (IP67)

    Camera
    Image Sensor2 MP CMOS
    Max. Resolution1920 (H) × 1080 (V)
    Min. Illumination0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light
    Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
    Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
    Signal SystemPAL/NTSC
    Light AlarmSolid Light Alarm (White Light)

    Lens
    Lens Type2.8 mm, 3.6 mm, 6 mm Fixed Lens
    Focal Length & FOV

    2.8 mm, horizontal FOV: 98°, vertical FOV: 51°, diagonal FOV: 115°

    3.6 mm, horizontal FOV: 76°, vertical FOV: 41°, diagonal FOV: 90°

    6 mm, horizontal FOV: 50°, vertical FOV: 27°, diagonal FOV: 58°
    Lens MountM12

    Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
    Image SettingsBrightness;Mirror;Sharpness;Anti-Banding;Smart Light
    Frame Rate

    TVI: 1080p@25fps/30fps

    CVI: 1080p@25fps/30fps

    AHD: 1080p@25fps/30fps

    CVBS: PAL/NTSC
    Day/Night ModeColor
    Wide Dynamic Range (WDR)Digital WDR
    Image EnhancementDWDR;BLC;HLC;Global
    Noise Reduction3D DNR/2D DNR
    White BalanceAuto/Manual
    White LightAuto/Off
    AGCYes

    Interface
    Video OutputSwitchable TVI/AHD/CVI/CVBS

    General
    MaterialPlastic
    Dimension161.1 mm × 70 mm × 70 mm (6.34" × 2.76" × 2.76")
    Approx. 229 g (0.50 lb)
    Operating Condition-40°C to 60°C (-40°F to140°F), Humidity: 90% or less (non-condensing)
    CommunicationHIKVISION-C
    LanguageEnglish
    Power Supply

    12 VDC ± 25%

    *You are recommended to use one power adapter to supply the power for one camera.
    ConsumptionMax. 2.4 W
    White Light RangeUp to 20 m

    Approval
    ProtectionIP67
