TP-Link TD-W9950 300Mbps Wi-Fi VDSL/ADSL Modem Router

DONANIM ÖZELLİKLERİ
Arabirim    1× 10/100 Mbps LAN/WAN Port
3× 10/100 Mbps LAN ports
1× RJ11 port
Buton    WPS/Wi-Fi Button
Reset Button
Power On/Off Button
Harici Güç Kaynağı    9V/0.85A
IEEE Standartları    IEEE 802.3, 802.3u
VDSL2 Standartları    ITU-T G.993.2, ITU-T G.993.5 (G.vector), ITU-T G.998.4 (G.INP)
ADSL Standartları    Full-rate ANSI T1.413 Issue 2, ITU-T G.992.1(G.DMT), ITU-T G.994.1 (G.hs), ITU-T G.995.1
ADSL2 Standartları    ITU-T G.992.3 (G.DMT.bis)
ADSL2+ Standartları    ITU-T G.992.5
Boyutlar ( W X D X H )    7.1 × 4.9 × 1.4 in (181.6 × 125.7 × 36.2 mm)
Anten    2 × 5dBi Fixed Omni-Directional Antennas

KABLOSUZ ÖZELLİKLERİ
Kablosuz Standartlar    IEEE 802.11b/g/n 2.4GHz
Kablosuz Hızı    300 Mbps at 2.4 GHz
Frekans    2.400 - 2.4835 GHz
İletim Gücü    <20dBm(EIRP)
Kablosuz Fonksiyonlar    Enable/Disable Wireless Radio, WMM, Wireless Statistics
Kablosuz Güvenlik    Supports 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions

YAZILIM ÖZELLİKLERİ
Quality of Service    QoS Remarking based on IPP/ToS, DSCP and 802.1p
Gelişmiş Özellikler    Traffic Shaping(ATM QoS) UBR, CBR, VBR-rt, VBR-nrt;
Dynamic Host Configuration Protocol (DHCP), DHCP relay;
Network Address Translation (NAT);
PVC/Ethernet Port Mapping
VLAN, 802.1P,
Static Routing,
DNS Relay, DDNS,
IGMP snooping V1/2
IGMP Multicast,
UPnP
Güvenlik    NAT Firewall,
SPI Firewall,
MAC / IP / Packet / Application / URL Filtering,
Denial of Service(DoS),
SYN Flooding,
Ping of Death
Yönetim    Web Based Configuration(HTTP),
Remote management,
Telnet management,
SSL for TR-069,
SNMP v1/2c,
SNMP over EOC,
Web Based Firmware Upgrade,
CWMP(TR-069),
Diagnostic Tools
Port Yönlendirme    Virtual Server, DMZ, ACL(Access Control List)
VPN Pass-Through    PPTP, L2TP, IPSec Pass-through
ATM/PPP Protokolleri    ATM Forum UNI3.1/4.0,
PPP over ATM (RFC 2364),
PPP over Ethernet (RFC2516),
IPoA (RFC1577/2225),
PVC - Up to 8 PVCs

DİĞERLERİ
Sertifika    CE, RoHS
Paket İçeriği    DSL Modem Router TD-W9950
External DSL Splitter
RJ11 DSL Cable
RJ45 Ethernet Cable
Quick Installation Guide
Power Adapter

Sistem Gereksinimleri    Windows 11/10/8.1/8/7/Vista/XP or Mac OS or Linux-based operating system
Ortam    Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
